High reputation China Fastest Digital Addressable RGB 5050LED Flexible LED Strip Light

Short Description:

LC8812B/WS2812B/SK6812 LED is 5050 RGB LED with IC built-in, it is very popular among customers,the same pin to pin function and lighting effect, same control way. DC5V Voltage, Each led is a pixel and cuttable, individual addressable. The led strip also can be customized with customers logo or label as request.


Product Detail

Product Tags

With our loaded encounter and considerate services, we have now been recognized as a trustworthy supplier for lots of worldwide consumers for High reputation China Fastest Digital Addressable RGB 5050LED Flexible LED Strip Light, Welcome to visit us at any time for organization marriage established.
With our loaded encounter and considerate services, we have now been recognized as a trustworthy supplier for lots of worldwide consumers for China Pixel LED Strip, dream color, Selling our products and solutions causes no risks and brings high returns to your company instead. It is our consistent pursuit to create value for clients. Our company is looking for agents sincerely. What are you waiting for? Come and join us. Now or never.

Product Specifications:

Product Name LC8812B/SK6812/WS2812B RGB LED Strip
LED type 5050 SMD LED
IC type LC8812B/SK6812/WS2812B
Emitting color Digital RGB
LED Q’ty 30led/m, 60led/m, 72led/m, 96led/m, 144led/m
Pixel Q’ty 30pixel/m, 60pixel/m, 72pixel/m, 96pixel/m, 144pixel/m
LED View angle 120 Degree
PCB Color White/Black
IP Rating IP20, IP65, IP67, IP68.
Length/Roll 5M/Roll, strip length can be customized
Working Voltage DC5V
Certification: CE, EMC, FCC, LVD, RoHS
CRI (Ra>): 80
Warranty(Year) 2-Years



Model

LED Qty

IC Qty

Voltage

Max Power

Gray Scale

Color

Width

LC-8812X30XM10X-5V

30

30

5V

9W/M

256

Digital RGB

10mm

LC-8812X60XM10X-5V

60

60

18W/M

256

10mm

LC-8812X72XM12X-5V

72

72

21.6W/M

256

12mm

LC-8812B96XM12X-5V

96

96

28.8W/M

256

12mm

LC-8812144XM12X-5V

144

144

43.2W/M

256

12mm

Application:

(1) Applicable for automobile and bicycle decoration, border or contour lighting

(2) Widely used for home decoration use, hotels, clubs, shopping malls

(3) Architectural decorative lighting, boutique atmosphere lighting

LED Strip Connection Diagram:

NOTE

1. The AC wiring must be connected to the ground wire to prevent electric shock.

2. The specification is only for regular quotation products, specific products have specified parameters, which are not within the scope of this specification.

The overload current of the main wire of the LED Strip is the sum of the currents of the sub-wires, so in actual engineering applications, the model of the main wire should be appropriately increased to prevent the wire from overheating and accidents.

FAQ

Q: What’s is the main market for our company?

A:Our clients all over the world. But we are selling more to EU and north America because the markets have high quality standard for LED products. The rate stands our turnover up to 70-80%.

Q: Can you do OEM or make new design products?

A:OEM can be done, we can do as customer request with different size, layout, customer logos and labels, and we made many new design to Customers according to their ideas.

Q: What payment way you accept?

A:T/T, Paypal, Western union all works to us.

Q: Do you supply free sample?

A: Yes, we accept sample order, we can ship some free sample for customer to test , but the buyer need to pay the shipping cost.

Q: Does all the LED product pass RoHs?

A: Yes, all of our led products pass RoHs, we use qualified material and have CE and RoHs Certificate.

With our loaded encounter and considerate services, we have now been recognized as a trustworthy supplier for lots of worldwide consumers for High reputation China Fastest Digital Addressable RGB 5050LED Flexible LED Strip Light, Welcome to visit us at any time for organization marriage established.
High reputation China Pixel LED Strip, Selling our products and solutions causes no risks and brings high returns to your company instead. It is our consistent pursuit to create value for clients. Our company is looking for agents sincerely. What are you waiting for? Come and join us. Now or never.
